Manufactured using high quality Lithium Iron Phosphate (LiFePO4) cells that produce considerable size and weight savings when compared to conventional Lead Acid Batteries.
Ideal replacement for gold trolleys and trundlers such as moto caddy, power caddy and others. Fraction of the weight, increased performance and much faster recharge time.
Mr Positive Gold Trundler Batteries are available in either 18ah or 22ahr sizes. Suitable battery charger can be added to the battery before adding the item to cart. We recommend a LiFePO4 specific CC/CV battery charger with an output voltage of 14.6v and a maximum output current rating off 4a.
These batteries are manufactured to our specifications in form factor to suit popular branded golf trundlers and trolleys, however they can be used for any deep cycle application providing manufacture max discharge, max discharge voltage and charge settings are followed at all times. Anderson style main output connectors are included with package.
12v 22ahr LiFePO4 Battery Pack
T-Bar Style to Anderson Adaptor Cable
The carry case is no longer part of this package and is not included.
Nominal Voltage: 12.8v
LiFePO4 Cell Configuration: 4S7P (3.2v 3ahr Cells)
Minimal Capacity: 22ah at 0.5c (11a) Discharge
Nominal Capacity: 22.5ah at 0.2c (4a) Discharge
Nominal Charge Current: 0.2c (4a)
Standard Charging Method: CC at 0.2c to 14.6v. CV 14.6v until current drops to <0.05c
Standard Charging Time: 5.5 Hours
Max Recommended Charge Current: 0.5c (0.2c Recommended)
Max Continuous Discharge Current: 1c @ 23 Degrees Celsius
Recommended Discharge Cut-Off Voltage: 10v
Dimensions: 168 x 128 x 126
You must use correct charger when charging this battery. The charger must be specifically designed for LiFePO4 batteries with suitable voltage to match the number of cells contained in this battery. Normal Lead Acid battery charges cannot be used. Mr Positive carries a suitable charger for this battery and it can be found below in the We Also Recommend section.
