MeanWell 12v 7.2a Battery Charger with XLR Connector

Calculate Shipping

Free Shipping [STANDARD] - $0.00
Excludes DG or bulk items (flooded or large lead acid batteries, large panels and generators).

MeanWell PB series 12v 7.2a battery charger for mobility scooters. This charger is terminated with the standard 3 pin XLR connector. Also known as the standard microphone socket.

The charger is single output providing 13.8v for charging 12v lead acid batteries.

Features:

Built-in passive PFC function compliance to EN61000-3-2
With AC ON-OFF switch
3 poles AC inlet with fuse holder
Protections: Short circuit / Overload / Over voltage / Over temperature
2 colour LED loading indicator

Specifications:

Output Voltage: 13.8v
Rated Current: 7.2a
Power Rating: 99.36w
Charging Type: 2 Stage
Input Voltage: 80-264v AC
Output Connector: 3 pin XLR
Dimensions: 180mm x 96mm x 49mm

Product brochure / datasheet can be downloaded by clicking the PDF icon just below the main image.

(MPWEL224)
