Li-Ion PCM for 25.2v-25.9v 7s (7 cell) Battery - 10a Max Discharge

$52.00
In Stock
Not available for pickup. Shipped within 24 hours.


Calculate Shipping

PCM (Protection Circuit Module) are designed to protect sensitive Lithium based batteries from over charge and over discharge. Mr Positive currently has a wide range of PCM designed for different cell configuration as well as different types of Lithium rechargeable batteries. Including Lithium Ion and Lithium Polymer batteries. PCM models are available with built in balancing function or without.

This model is suitable for 7 cell Li-Ion (Lithium Ion) battery configurations.

Full PDF data sheet for this product can be downloaded below the specifications.

Specifications:

Charging Voltage: 29.4v
Max Charge Current: 10a
Max Discharge Current: 10a
Own Current Consumption: 20uA
Over Charge Detection Voltage: 4.35v +/- 0.025v
Over Discharge Detection Voltage:: 2.50v +/- 0.05v

Product brochure / datasheet can be downloaded by clicking the PDF icon just below the main image.

(PCM7SLIION)

SKU PCM7SLIION
Barcode # 2000000003986
