LCD 200a 200v Power Meter with External Shunt

All in one elegant solution to keep an eye on your project's power usage. This unit has a range of up to 200v and 200as DC as well as aggregation of power. Which makes it an ideal solution for DIY power projects, solar installations that do not exceed 200a.

200a external shunt is included.

Features:

Real time information
Large backlit display
Aggregated energy throughput
Power Consumption: 0.2W
Measurement speed: 2 times/s

Specifications:

Width: 90mm
Height: 50mm
Depth 25mm
Weight: 62g
DC Voltage Range: 6.5v, 200v
Dc Voltage Accuracy: 1%
Dc Current Range: 0a, 200a
DC CUrrent Accuracy: 1%
Shunt Included: Yes (External)

Product brochure / datasheet can be downloaded by clicking the PDF icon just below the main image.
